PUT IT ON!
Attachment 29530
Printable View
PUT IT ON!
Attachment 29530
LOL
Ha Ha!! I had to order a plug and some wire terminals for the license plate wiring. My OCD will not let me just splice it in unfortunately.
Plus I need to get my electrical fan setup running before it gets too hot here. I mounted the electric fan inside the stock fan shroud last weekend and just wired up a PWM Controller. The PWM controller acts just like the stock Aux Fan controller does. It ramps up the fan speed depending on the demand. Soft start technology is easier on the DC fan and the alternator.
Auto Cool Guy
http://www.autocoolguy.com
With power transistors, no contacts to arc and burn out over time.
PWM also limits in-rush current (soft start) when starting motors from a dead stop.
Relays used for starting DC fan motors is not a good idea.
Relays used to start DC fan motors from a dead stop will have arcing that limits the life of the relay.
The relay contacts could be welded together that will put your fans in high RPM and drain your battery!
The relay contacts could be destroyed leaving you without radiator fan control and engine boiling!
https://uploads.tapatalk-cdn.com/201...e01b85b0cf.jpg
https://uploads.tapatalk-cdn.com/201...ec385273f8.jpg
https://uploads.tapatalk-cdn.com/201...f7ef321ae8.jpg
https://uploads.tapatalk-cdn.com/201...4f68eef50a.jpg
Offset the fan inside the shroud to clear the water pump shaft
https://uploads.tapatalk-cdn.com/201...4563908b43.jpg
https://uploads.tapatalk-cdn.com/201...1bf68e6394.jpg
https://uploads.tapatalk-cdn.com/201...44c3e64512.jpg
I digg the new fan setup Gary!
That CSL bootlid is always a great piece. It will compliment the rear diffuser so nicely.
Gary is your drug bin all sealed from water too? I wouldn't want a water droplet to close a circuit that shouldn't be!!
Thanks. Ya I can't wait to get the CSL bottled installed!Quote:
Originally Posted by derbo
Well not completely but the owner of the company says it's completely ok to install these inside the engine bay. I was concerned about this and emailed him with several questions about where to mount it. He said bus companies mount them inside the engine bay with no issues. I might build a cover for it out of a ABS plastic sheet.Quote:
Originally Posted by Rovert
These controllers are completely water proof. You can actually submerge them in water and they will still work. I found these after I bought the other one.
http://dccontrol.com/constant_temper...ontrollers.htm
Very cool Gary. BTW, love the 'Christmas Story' reference!
Sent from my SM-G935V using Tapatalk
Got the electrical plug and wires from FCP Euro. Time to install this bad boy!
https://uploads.tapatalk-cdn.com/201...2657773aca.jpg
Cool picture opportunity.
https://uploads.tapatalk-cdn.com/201...c17be49874.jpg
Can you let me know what you purchased from FCP? I got the E92 LED plate lights and a couple plugs and connectors but I don't think enough. LOL
You need this if you want to plug it into the stock plug. I bought two plugs and four wires so if you want the extra ones I will send them to ya.
(1) 61 13 6 931 929 UNIVERSAL PIN TERMINAL
(2) 61 13 0 006 664 PIN-CONTACT WIRES
http://www.m3forum.net/m3forum/showp...6&postcount=21
