Derbo's ZHP

Kalim found out that there are two blue plugs and more information about the MK60 vs the MK20 DSC system.


Looking in the ST034 pdf I find this for the MK60 DSC.

There are two types of sensors used in the rear axle of the E46:
• The short sensor is used on the 325i (any transmission) and 330i automatic.
• The long sensor is used on the 330i manual transmission version.


Doesn't say much about the M3 but if REALOEM is correct, it uses the short one like all other E46s except 330i manuals. :facepalm. Looks like I need to find some spacers to run temporarily till I can get a set of wheel sensors.

Grey Plug:
inductive sensors
Blue plug:
magnetoresistive sensors

Quote:

---

Originally Posted by derbo

Kalim found out that there are two blue plugs.

Oddly enough 330i manuals have one abs sensor. The rest of the cars autos/M3 use another blue plug sensor. how strange.

---

Yep, exactly what I was saying I read in the tech docs. It's weird how they singled out just the 330 manuals.

Do you have the ST034 document?

http://www.pelicanparts.com/cgi-bin/...9%2C%20each%20


There is it is..

E46 323i/Ci w/ DSC (from 9/00), 325i/Ci w/o DSC (from 9/01), 325i/Ci w/ DSC (through 02/03), 325i Wagon w/ DSC (9/00-02/03), 330i/Ci w/ auto (from 9/00), M3 (from 9/02), each

of course the 330i manual has the different one..wtf bmw?! lol

Yup.

Quote:

---

Originally Posted by cyberkaa

Yup.

---

I may have some stuff that could be of importance to you. Will follow up tomorrow. Goodnight :hi

Quote:

---

Originally Posted by derbo

I may have some stuff that could be of importance to you. Will follow up tomorrow. Goodnight :hi

---

Sounds good! Night :hi

Minor setback. The wheel sensors for the 330i are significantly longer. I thought spacing them out meant like two washers or so. It looks to be more than that.

Attachment 7509


I'm going to order the abs sensors and just call it a day.


Sent from my iPhone using Tapatalk 2

Found one spare sensor if you want to get that speedo working, haha.

Quote:

---

Originally Posted by cyberkaa

Found one spare sensor if you want to get that speedo working, haha.

---

I may have to take you up on this and get it from you on monday.


Tuesday I've made an appointment with one of the old techs at work to replace the input seal on the diff. If I have a working speedo, awesome, if not, I can wait a little longer haha.
